Beschreibung
| NW Ø (mm) |
PN | Anschlussmaß Connection(mm) |
Außen-Ø O.D. (mm) |
Lochkreis Hole Circle (mm) |
Schrauben- menge Amount srews |
Gewinde- größe Thread |
Art.-Nr. |
| 32 | 10/16 | 42,4 | 140 | 100 | 4 | M 16 | 5750-0032042 |
| 40 | 10/16 | 48,3 | 150 | 110 | 4 | M 16 | 5750-0040048 |
| 50 | 10/16 | 60,3 | 165 | 125 | 4 | M 16 | 5750-0050060 |
| 65 | 10/16 | 76,1 | 185 | 145 | 4 | M 16 | 5750-0065076 |
| 80 | 10/16 | 88,9 | 200 | 160 | 8 | M 16 | 5750-0080089 |
| 100 | 10/16 | 108,0 | 220 | 180 | 8 | M 16 | 5750-0100108 |
| 100 | 10/16 | 114,3 | 220 | 180 | 8 | M 16 | 5750-0100114 |
| 125 | 10/16 | 133,0 | 250 | 210 | 8 | M 16 | 5750-0125133 |
| 125 | 10/16 | 139,7 | 250 | 210 | 8 | M 16 | 5750-0125139 |
| 150 | 10/16 | 159,0 | 285 | 240 | 8 | M 20 | 5750-0150159 |
| 150 | 10/16 | 168,3 | 285 | 240 | 8 | M 20 | 5750-0150168 |
| 200 | 10 | 219,1 | 340 | 295 | 8 | M 20 | 5750-1200219 |
| 250 | 10 | 273,0 | 395 | 350 | 12 | M 20 | 5750-1250273 |
| 300 | 10 | 323,9 | 445 | 400 | 12 | M 20 | 5750-1300324 |
| 200 | 16 | 219,1 | 340 | 295 | 12 | M 20 | 5750-2200219 |
| 250 | 16 | 273,0 | 405 | 335 | 12 | M 24 | 5750-2250273 |
| 300 | 16 | 323,9 | 460 | 410 | 12 | M 24 | 5750-2300324 |
